NovaTex is a screw-free system which is often used for point of sale signage in retail environments. It is also used in showrooms to provide striking images, both non illuminated and when backlit.

Features and application

Illuminated for impressive visuals

The 65mm and 83mm frames provide distinctive visuals when illuminated using LEDs, and all power supplies are housed within the box – both convenient and providing an elegant simplicity. At just 100mm in depth, the double-sided extrusion has the facility for internal strengthening to prevent distortion. This facility can also be used to hang boxes. All five options are completely screw free making them aesthetically ideal for low level signage. At just 18mm deep the non-illuminated frame can be used to display images of almost any size. Although the 40mm frame is a great option for non-illuminated signage, it is more commonly backlit with LEDs. Using slim drivers to power the LEDs, the power units can often be concealed within the frame.

Easy to install

Printed skins are supplied with a silicone edge stitched around the perimeter. This allows the installer to simply push the skin into the extrusion with just their thumb, no tools required. The skin will have a pull tab located on one edge to allow for rapid removal when updating the graphics. NovaTex is suited to a range of retail and other settings, including at point of sale instore, within car showrooms and at airports.

Request A Quote

Please enter your dimension requirements
Click or drag a file to this area to upload.
If you have a sketch of your requirements please upload here (max file size 5mb, accepted files: jpegs, pngs, pdfs and word docs)
Please let us know any additional information for your requirements.

Benefits and Options

Stylish design

Any standard RAL

Backlit with LEDs

Simple to install, no tools required

Five depths available

Screw free appearance
